Concealed Cup Hinge Metalla 110 Clip 105° half overlay
Item code: L-HS11021
Item code copied!
Concealed Cup Hinge Metalla 110 Clip 105° half overlay
Concealed Cup Hinge Metalla 110 Clip 105° half overlay
Concealed Cup Hinge Metalla 110 Clip 105° half overlay
Concealed Cup Hinge Metalla 110 Clip 105° half overlay
  • new New
  • discount Discount
Concealed Cup Hinge Metalla 110 Clip 105° half overlay
Concealed Cup Hinge Metalla 110 Clip 105° half overlay
Concealed Cup Hinge Metalla 110 Clip 105° half overlay
Concealed Cup Hinge Metalla 110 Clip 105° half overlay

Concealed Cup Hinge Metalla 110 Clip 105° half overlay

Item code: L-HS11021
Item code copied!
€0.64 €1.02
pcs (with VAT)
Item in stock.
Delivery Time: 1-3 days
Half-overlay hinge with soft close Technical specifications:Side adjustment: ±3 mmHeight adjustment: ±2 mmDepth adjustment: ±2 mm...
Min. 1
Description
Half-overlay hinge with soft close

Technical specifications:
  • Side adjustment: ±3 mm
  • Height adjustment: ±2 mm
  • Depth adjustment: ±2 mm
Product Details

Data sheet

BrandHäfele
Comfort functions opening/closing Soft close, Self close
Type of facade Half
Door thickness, mm 15-24
Door material Board
Opening angle, ° 105
Cup depth, mm 12
Cup width, mm 35
Material steel
Series Metalla 110
Screw drilling dimensions, mm 48/6
Colour nickel
Vendor item no. 311.04.206
Installation CLIP/SM quick fixing
