Pull out frame, Häfele Dresscode
Item code: X80634515
Item code copied!
Pull out frame, Häfele Dresscode
Item code: X80634515
Item code copied!
€105.47
€167.42
set
(with VAT)
Item is available for special order. Place your order as usual and we will contact you to confirm the shipping date.
Delivery Time: 7-15 days
Pull out frame
Technical specifications:
- Modular system: choose frame and desired accessory for it: box, shelf, jewellery tray, trousers rails
- With full-extension rails with integrated pull-in and soft-close mechanism
- Simple mounting removal or position adjustment without tools thanks to special foldable brackets
- Option to order decorative front façade in aluminium or make façade from board
- Crossbar profile can be cut to desired dimensions
- Recommended mounting height max 900 mm
Mounting method:
- Rails are fixed with foldable brackets inserted into Ø5 mm drill holes
- Frame is placed on rails
*Note: table of dimensions indicates internal cabinet module depth
DressCode profile system and wardrobe accessories mounting (video)
For installation in the DressCode aluminium profile system crossbars with perforation (2 pcs) are additionally ordered
For installation in boards with hinged or sliding doors gaskets 21 or 42 mm thick are additionally ordered
Set includes:
- Side aluminium profiles – 2 pcs
- Cross aluminium profiles – 2 pcs
- Rails L-500 mm with foldable brackets – 1 set
Data sheet
| Brand | Häfele |
|---|---|
| Height, mm | 56 |
| Load capacity, kg | 15 |
| Material | aluminium/plastic |
| Series | DressCode |
| Width, mm | 820 |
| External module width, mm | 900 |
| External module depth, mm | ≥520 |
| Colour | anthracite |
| Vendor item no. | 806.34.515 |
Product photos are intended for illustrative purposes only and are examples. The video links included in the product description are for informational purposes only; therefore, the information presented in them may differ from the actual product. Original product colors, inscriptions, parameters, measurements, sizes, functions, and/or other product features may appear differently in reality due to their visual characteristics, so please rely on the product specifications provided in the product description.
